YZE Series Electromagnetic Braking Three-Phase Induction Motor for Crane and Metallurgical Applications

Duty S3 40% Specification of YZE Series Electromagnetic Braking Three-Phase Induction Motor for Crane and Metallurgical Applications

Model	Syn Speed r/min	Rated Power kW	I1 A	Tst/Tn	Tmax/Tn	Ist/In	Rated Speed r/min	Eff %	Power Factor cosφ	Brake Breaking Torque N.m	Brake Work Voltage V	Brake Power W	Weight kgs
YZE 112M-4	1500	1.5	4.25	2.4	2.5	4.47	1380	70	0.76	40	170/24	100	66
YZE 132M1-4	1500	2.2	5.9	2.5	2.5	5.16	1400	74	0.75	75	170/24	110	92
YZE 132M2-4	1500	4	10	2.5	2.5	5.54	1410	75	0.78	75	170/24	100	104
YZE 160M1-4	1500	11	25	2.5	2.5	4.9	1430	79	0.8	150	170/24	200/175	138
YZE 112M-6	1000	1.5	4.25	2.7	2.4	4.47	920	69.5	0.765	40	170/24	100	66
YZE 132M1-6	1000	2.2	5.9	2.9	3.1	5.16	935	74	0.745	75	170/24	110	92
YZE 132M2-6	1000	3.7	8.8	2.8	3	5.54	912	79	0.79	75	170/24	110	104
YZE 160M1-6	1000	5.5	12.5	2.7	2.5	4.9	933	8.6	0.83	150	170/24	200/175	138
YZE 160M2-6	1000	7.5	15.9	2.9	2.4	5.52	948	83	0.86	150	170/24	200/175	151
YZE 160L-6	1000	11	24.6	2.9	2.7	6.17	953	84	0.852	150	170/24	200/175	172
YZE 160L-8	750	7.5	18	2.7	2.5	5.1	705	82.4	0.766	150	170/24	200/175	172
YZE 180L-8	750	11	25.8	2.5	2.6	4.9	694	80.9	0.811	200	170/24	164/140	237
YZE 200L-8	750	15	33.1	2.8	2.7	6.1	710	86.2	0.8	300	170/24	240/230	326
YZE 225M-8	750	22	45.8	2.9	2.9	6.2	712	87.5	0.834	450	170/24	230	413
YZE 250M1-8	750	30	63.3	2.54	2.7	5.47	694	85.7	0.84	-	-	-	-

Duty S3 25%_60% Specification of YZE Series Electromagnetic Braking Three-Phase Induction Motor for Crane and Metallurgical Applications

Model	Syn Speed r/min	S3 25% Rated Power kW	S3 25% I1 A	S3 25% Rated Speed r/min	S3 60% Rated Power kW	S3 60% l1 A	S3 60% Rated Speed r/min	Tst/Tn	Tmax/Tn	Ist/In	Eff %	Power Factor cosφ	Brake Breaking Torque N.m	Brake Work Voltage V	Brake Power W	Weight kgs
YZE 112M-4	1500	1.8	4.9	1310	1.1	2.7	1400	2.4	2.5	4.47	70	0.76	40	170/24	100	66
YZE 132M1-4	1500	2.5	6.5	1385	1.8	5.3	1420	2.5	2.5	5.16	74	0.75	75	170/24	110	92
YZE 132M2-4	1500	4.5	11.5	1400	3.5	9	1425	2.5	2.5	5.54	75	0.78	75	170/24	100	104
YZE 160M1-4	1500	13	29	1415	9.5	22	1440	2.5	2.5	4.9	79	0.8	150	170/24	200/175	138
YZE 112M-6	1000	1.8	4.9	892	l.l	2.7	946	2.7	2.4	4.47	69.5	0.765	40	170/24	100	66
YZE 132M1-6	1000	2.5	6.5	920	1.8	5.3	950	2.9	3.1	5.16	74	0.745	75	170/24	110	92
YZE 132M2-6	1000	4	9.2	915	3	7.5	940	2.8	3	5.54	79	0.79	75	170/24	110	104
YZE 160M1-6	1000	6.3	14.1	922	5	11.5	940	2.7	2.5	4.9	8.6	0.83	150	170/24	200/175	138
YZE 160M2-6	1000	8.5	18	943	6.3	14.2	956	2.9	2.4	5.52	83	0.86	150	170/24	200/175	151
YZE 160L-6	1000	13	28.7	936	9	20.6	964	2.9	2.7	6.17	84	0.852	150	170/24	200/175	172
YZE 160L-8	750	9	21	694	6	15.6	717	2.7	2.5	5.1	82.4	0.766	150	170/24	200/175	172
YZE 180L-8	750	13	30	675	9	21.5	710	2.5	2.6	4.9	80.9	0.811	200	170/24	164/140	237
YZE 200L-8	750	18.5	40	697	13	28.1	714	2.8	2.7	6.1	86.2	0.8	300	170/24	240/230	326
YZE 225M-8	750	26	53.5	701	18.5	40	718	2.9	2.9	6.2	87.5	0.834	450	170/24	230	413
YZE 250M1-8	750	35	74	681	26	56	702	2.54	2.7	5.47	85.7	0.84	-	-	-	-

IM1001_IM1003 Mounting Size of YZRE Series Electromagnetic Braking Wound-Rotor Three-Phase Induction Motor for Crane and Metallurgical Applications

Frame	A	A/2	B	C	D	D1	E	E1	F	G	H	K	Bolt Diameter	AB	AC	BB	HA	HD	L
112M	190	95	140	70	32	-	80/110	-	10	27	112	12	M10	250	245	235	18	335	565
132M	216	108	178	89	38	-	-	-	10	33	132	12	M10	275	285	260	20	365	645
160M	254	127	201	108	48	-	-	-	14	42.5	160	15	M12	320	325	290	25	425	870
160L	254	127	254	108	48	-	-	-	14	42.5	160	15	M12	320	325	335	25	425	920
180L	279	139.5	279	121	55	M36×3	-	82	14	19.9	180	15	M12	360	360	380	25	465	1085
200L	318	159	305	133	60	M42×3	140	105	16	21.4	200	19	M16	405	405	400	28	510	1170
225M	356	178	311	149	65	M42×3	140	105	16	23.9	225	19	M16	455	430	410	28	545	1320
250M	406	203	349	168	70	M48×3	140	105	18	25.4	250	24	M20	515	480	510	30	605	1420

IM3011_IM3013 Mounting Size of YZE Series Electromagnetic Braking Three-Phase Induction Motor for Crane and Metallurgical Applications

Frame	Flange No.	D	D1	E	E1	F	G	M	N	P	S	Bolt Diameter	T	Holes(PCS)	HD	L	LA	LB
112M	FF215	32	-	80	-	10	27	215	180	250	15	M12	4	4	220	565	14	485
132M	FF265	38	-	80	-	10	33	265	230	300	15	M12	4	4	230	645	14	565
160M	FF300	48	-	110	-	14	42.5	300	250	350	19	M16	5	4	260	870	18	760
160L	FF300	48	-	110	-	14	42.5	300	250	350	19	M16	5	4	260	920	18	810
180L	FF300	55	M36×3	110	82	14	19.9	300	250	350	19	M16	5	4	280	1085	18	975
200L	FF400	60	M42×3	140	105	16	21.4	400	350	450	19	M16	5	8	320	1170	20	1030
225M	FF400	65	M42×3	140	105	16	23.9	400	350	450	19	M16	5	8	320	1320	20	1180
250M	FF500	70	M48×3	140	105	18	25.4	500	450	550	19	M16	5	8	355	1490	22	1630
