YR Series (IP54) Wound Rotor Three-Phase Induction Motor
  1. YR Series (IP54) Wound Rotor Three-Phase Induction Motor

YR Series (IP54) Wound Rotor Three-Phase Induction Motor

Send Inquiry Live chat
  • Product Detail
Spefication of YR Series (IP54) Wound Rotor Three-Phase Induction Motor

Spefication of YR Series (IP54) Wound Rotor Three-Phase Induction Motor

Model Rated Power
(KW) 		Rated Current
(A) 		Rated Speed
(r/min) 		Efficiency
(%) 		Power Factor
(cosφ) 		Max Torque/Rated Torque Rotor Voltage
(V) 		Rotor Current
(A) 		Noise
(dBA) 		Vibration
(mm/s) 		Moment of inertia
(kg·m²)
160M-4 7.5 15.8 1444 87.5 0.83 3 250 19.5 90 2.8 0.23
160L-4 11 22.8 1426 89.5 0.83 3 276 25 90 2.8 0.27
180L-4 15 30 1463 89.5 0.83 3 264 36 94 2.8 0.24
200L-4 37 74.4 1462 90 0.84 3 542 42 94 2.8 0.36
200L1-4 18.5 36 1462 90 0.85 3 264 44 94 2.8 0.36
200L2-4 22 43 1467 90 0.86 3 305 45 94 2.8 0.4
225M-4 45 89 1465 90 0.85 3 474 58 98 2.8 0.77
225M2-4 30 59 1473 90 0.86 3 378 49 98 2.8 0.77
250M1-4 37 71 1475 91.5 0.86 3 287 79 98 3.5 1.03
250M2-4 45 86 1477 91.5 0.87 3 341 81 100 3.5 0.17
280S-4 55 104 1457 91.5 0.88 3 501 67 100 3.5 2.27
280M-4 75 140 1480 92.5 0.88 3 429 107 103 3.5 2.65
315S-4 90 170 1483 92.5 0.87 4 548 100 103 3.5 4.65
315M1-4 110 204 1485 93 0.88 4.5 526 127 103 3.5 5.22
315M2-4 132 245 1485 93.5 0.88 4.5 602 133 106 3.5 5.68
315L1-4 160 294 1486 94 0.88 4.5 722 134 106 3.5 6.47
355-4 250 442 1488 94.5 0.91 3 615 243 106 3.5 15.13
355M1-4 160 293 1485 93.3 0.89 3 352 277 106 3.5 11.54
355M2-4 185 338 1485 93.5 0.89 3 385 293 106 3.5 12.58
355L1-4 200 363 1486 94 0.89 3.3 423 287 106 3.5 13.04
355L2-4 220 400 1488 94 0.89 3.3 483 277 106 3.5 14.02
355L3-4 250 454 1488 94 0.89 3.5 529 286 106 3.5 15.13
355L4-4 280 509 1489 94 0.89 3.5 605 280 106 3.5 16.98
400M1-4 280 526 1488 94 0.89 3.5 545 311 108 3.5 21.51
400M2-4 315 592 1489 94 0.89 3.5 595 320 108 3.5 23.54
400M3-4 355 657 1489 94.5 0.87 3.5 674 318 108 3.5 26.07
400M4-4 400 739 1490 94.5 0.87 3.5 776 311 108 3.5 28.35
400L1-4 450 810 1490 94.5 0.89 3 874 320 108 3.5 33.01
400L2-4 500 900 1490 94.8 0.89 3 977 308 108 3.5 35.6
4501-4 500 897 1492 95.2 0.89 3 722 412 111 3.5 37.31
4502-4 560 1003 1493 95.3 0.89 3 867 384 111 3.5 41.27
4503-4 630 1115 1493 95.4 0.9 3 878 427 111 3.5 46.34
4504-4 710 1255 1494 95.5 0.9 3 1085 389 111 3.5 51.5
4505-4 800 1413 1494 95.6 0.9 3 1211 424 111 3.5 57.31
132M1-6 3 8 949 80.5 0.69 2.8 206 9.5 82 1.8 0.2
132M2-6 4 107 949 82 0.69 2.8 230 11 82 1.8 0.21
160M-6 5.5 12.9 963 84 0.77 3 166 21.8 82 2.8 0.28
160L-6 7.5 17.8 947 86 0.74 2.8 266 18 85 2.8 0.32
180L-6 11 22.9 970 87.5 0.81 2.8 316 23 88 2.8 0.35
200L1-6 15 32 972 88.5 0.81 2.8 193 49 88 2.8 0.53
225M1-6 18.5 38 975 88.5 0.83 2.8 195 60 88 2.8 0.77
225M2-6 22 45 977 89.5 0.83 2.8 230 60 88 2.8 0.88
250M1-6 30 60 982 90 0.84 2.8 282 66 88 3.5 1.51
250M2-6 37 74 984 90.5 0.84 2.8 327 70 91 3.5 1.66
280S-6 45 88 969 91.5 0.85 2.8 364 76 94 3.5 3.06
280M-6 55 107 986 92 0.85 2.8 428 79 94 3.5 3.23
315S-6 75 144 989 93 0.85 3 421 108 98 3.5 7.47
315MI-6 90 173 989 92 0.86 3 518 105 98 3.5 7.47
315M2-6 110 210 991 93.5 0.85 3 612 108 98 3.5 9.86
315L1-6 132 251 992 93 0.86 3 608 131 98 3.5 8.7
355M1-6 132 251 989 92.8 0.86 2.5 302 269 102 3.5 14.54
355M2-6 160 304 989 92 0.87 3 346 283 98 3.5 9.86
355L1-6 185 347 991 93 0.87 2.8 367 305 98 3.5 10.8
355L2-6 200 378 990 93.5 0.86 2.8 443 275 102 3.5 19.31
355L3-6 220 416 991 93.5 0.86 2.8 492 272 102 3.5 20.5
355L4-6 250 469 991 93 0.87 2.8 476 316 98 3.5 10.8
400M1-6 250 482 991 93.8 0.84 3 545 274 105 3.5 30.76
400M2-6 280 522 991 94.8 0.84 3 578 290 105 3.5 32.75
400M3-6 315 586 992 95 0.86 3 655 287 105 3.5 36.07
400M4-6 355 660 992 95 0.86 3 736 288 105 3.5 39.38
400L1-6 400 742 993 95.2 0.86 2.8 870 274 105 3.5 46.18
400L2-6 450 835 994 95.2 0.86 2.8 958 280 105 3.5 51.49
400L3-6 500 917 993 95.2 0.87 2.8 1064 279 105 3.5 53.26
4501-6 500 916 994 95.3 0.87 2.8 972 306 105 3.5 54.81
4502-6 560 1025 994 95.4 0.87 2.8 1080 306 105 3.5 58.5
4503-6 630 1152 994 95.5 0.87 2.8 1216 306 105 3.5 66.03
4504-6 710 1297 994 95.6 0.87 2.8 1390 306 105 3.5 72.88
160M-8 4 10.5 703 82.5 0.69 2.4 216 12 78 2.8 0.27
160L-8 5.5 14.1 714 83 0.71 2.4 230 15.5 78 2.8 0.31
180L-8 7.5 17.7 721 85 0.73 2.4 261 19 82 2.8 0.31
200L1-8 11 26 726 86 0.73 2.4 159 44 82 2.8 0.52
225M1-8 15 35 728 88 0.75 2.4 174 55 85 2.8 0.87
225M2-8 18.5 42 730 89 0.75 2.4 212 55 85 2.8 1.02
250M1-8 22 47 733 89 0.87 2.4 203 68 86 3.5 1.51
250M2-8 30 63 735 89.5 0.77 2.4 256 73 90 3.5 1.73
280S-8 37 76 715 90.5 0.79 2.4 290 79 87 3.5 2.97
280M-8 45 93 736 91.5 0.8 2.4 372 75 90 3.5 3.4
315S-8 55 109 739 91 0.84 3 229 146 93 3.5 7.47
315M1-8 75 147 740 92 0.84 3 306 148 96 3.5 9.06
315M2-8 90 191 740 93.2 0.77 2.8 549 9g 96 3.5 10.39
315L1-8 110 226 743 92.5 0.8 3.2 635 104 96 3.5 10.1
315L2-8 132 271 743 93.5 0.76 3 584 135 96 3.5 15.05
355M1-8 110 233 742 92 0.78 2.4 281 239 99 3.5 15.01
355M2-8 132 278 742 92.4 0.78 2.5 330 244 99 3.5 16.72
355L1-8 160 300 739 93 0.87 2.6 458 210 99 3.5 19.53
355L2-8 185 389 743 92.6 0.78 2.6 448 252 99 3.5 22.34
355L3-8 200 403 743 92 0.82 3 491 248 99 3.5 23.59
355L4-8 220 455 744 93 0.79 2.6 544 246 99 3.5 26.4
400M1-8 220 461 742 93 0.78 2.8 422 313 99 3.5 33.92
400M2-8 250 530 743 93 0.77 2.8 475 315 102 3.5 37.91
400M3-8 280 587 744 94.2 0.77 2.8 542 308 102 3.5 41.92
400L1-8 315 658 744 94.5 0.77 2.8 633 297 102 3.5 45.24
400L2-8 355 732 744 94.5 0.78 2.8 691 306 102 3.5 49.23
400L3-8 400 824 744 94.5 0.78 2.8 760 314 102 3.5 53.88
4501-8 400 813 745 94.6 0.79 2.8 704 337 102 3.5 54.87
4502-8 450 914 745 94.7 0.79 2.8 775 345 102 3.5 58.66
4503-8 500 1014 745 94.8 0.79 2.8 861 344 102 3.5 66.08
4504-8 560 1134 745 95 0.79 2.8 969 342 102 3.5 74.44
315S-10 40 101 592 92.5 0.73 2.4 351 77 93 3.5 6.42
315M1-10 55 124 592 92.5 0.73 2.4 411 81 93 3.5 7.13
315M2-10 75 159 591 92 0.78 2.8 574 79 96 3.5 9.09
315L1-10 90 202 593 92.8 0.73 2.4 672 80 96 3.5 9.98
355M1-10 90 203 593 92.5 0.73 2.5 261 209 96 3.5 15.22
355M2-10 110 236 592 92 0.77 2.8 289 229 99 3.5 18.03
355L1-10 132 279 592 92 0.78 2.8 340 234 99 3.5 21.15
355L2-10 160 353 594 93 0.74 2.6 435 222 99 3.5 23.96
400M1-10 185 401 594 93.5 0.75 2.8 401 276 99 3.5 38.58
400M2-10 200 433 594 93.5 0.75 2.8 435 275 99 3.5 41.56
400M3-10 220 477 594 93.5 0.75 2.8 474 277 99 3.5 45.28
400L1-10 250 539 595 94 0.75 2.8 547 273 102 3.5 51.24
400L2-10 280 603 595 94 0.75 2.8 608 275 102 3.5 56.44
400L3-10 315 679 595 94 0.75 2.8 684 274 102 3.5 62.4
4501-10 350 750 596 94.6 0.76 2.6 670 314 102 3.5 63.35
4502-10 400 833 596 94.7 0.77 2.6 766 310 102 3.5 73
4503-10 450 937 596 94.8 0.77 2.6 803 333 102 3.5 80.72
4004-10 500 1026 596 94.9 0.78 2.6 894 332 102 3.5 90.37
355M1-12 55 128 493 92 0.71 2.4 217 153 95 3.5 14.16
355M2-12 75 174 494 92.5 0.71 2.4 284 158 95 3.5 17.14
355L2-12 90 208 494 92.5 0.71 2.4 335 160 95 3.5 19.59
355L3-12 110 254 494 92.5 0.71 2.4 410 160 95 3.5 23.44
355L4-12 132 295 493 92 0.74 2.2 478 164 95 3.5 26.24
400M1-12 132 299 495 93.2 0.72 2.5 305 256 99 3.5 35.95
400M2-12 160 362 495 912 0.72 2.5 373 253 99 3.5 42.65
400M3-12 185 418 495 93.5 0.72 2.5 420 260 99 3.5 47.11
400L1-12 200 445 495 93.5 0.73 2.5 454 260 99 3.5 51.58
400L2-12 220 490 495 93.5 0.73 2.5 502 259 99 3.5 56.05
400L3-12 250 556 495 93.5 0.73 2.5 561 263 102 3.5 62
4501-12 250 548 496 93.6 0.74 2 594 249 102 3.5 64.01
4502-12 280 614 496 93.7 0.74 2 679 244 102 3.5 69.2
4503-12 315 689 496 93.8 0.74 2.2 794 235 102 3.5 73.66
4504-12 355 775 496 94 0.74 2.2 912 230 102 3.5 81.38
4505-12 400 860 496 94.2 0.75 2.2 953 248 102 3.5 91.04
IMB3 Mounting Size of YR Series (IP54) Wound Rotor Three-Phase Induction Motor

IMB3 Mounting Size of of YR Series (IP54) Wound Rotor Three-Phase Induction Motor

Frame A B C D E F G H K Terminal Box
D1 		Terminal Box
D2 		B1 AA AB AC HA HD BB L
132 216 178 89 38 80 10 33 132 12 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 20 59 275 285 17 360 360 645
160M 254 210 108 48 110 14 42.5 160 15 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 25 66 320 325 20 420 290 758
160L 254 254 108 48 110 14 42.5 160 15 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 25 66 320 325 20 420 335 800
180L 279 279 121 55 110 14 49 180 15 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 29 81 360 360 22 460 380 870
200L 318 305 133 55 110 16 49 200 19 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 31 70 388 397 25 495 420 1020
225M 356 311 149 60 110 18 53 225 19 M30x2.0(φ13-18)x1 M30x2.0(φ13-18)x1 36 75 431 460 28 520 430 1045
250M 406 349 168 65 140 18 58 250 24 M42x2.0(φ22-32)x1 M36x2.0(φ18-25)x1 40 80 490 495 30 625 490 1170
280S 457 368 190 75 140 20 67.5 280 24 M42x2.0(φ22-32)x1 M36x2.0(φ18-25)x1 38 85 550 550 35 670 490 1264
280M 457 419 190 75 140 20 67.5 280 24 M42x2.0(φ22-32)x1 M36x2.0(φ18-25)x1 38 85 550 550 35 670 540 1315
315S 508 406 216 80 170 22 71 315 28 M42x2.0(φ13-18)x3 M50x1.5(φ32-38)x1 48 120 628 620 45 837 570 1490
315M 508 457 216 80 170 22 71 315 28 M42x2.0(φ13-18)x3 M50x1.5(φ32-38)x1 48 120 628 620 45 837 680 1600
315L 508 508 216 80 170 22 71 315 28 M42x2.0(φ13-18)x3 M50x1.5(φ32-38)x1 48 120 628 620 45 837 680 1660
355M 610 560 254 95 170 25 86 355 28 M64x2.0(φ37-44)x3 M64x2.0(φ37-44)x1 52 116 730 710 52 920 913 1820
355L 610 630 254 95 170 25 86 355 28 M64x2.0(φ37-44)x3 M64x2.0(φ37-44)x1 52 116 730 710 52 920 913 -
400M 686 630 280 110 210 28 100 400 35 M72x2.0(φ45-52)x3 M64x2.0(φ37-44)x3 55 120 806 856 45 1078 970 2110
400L 686 710 280 120 210 32 109 400 35 M72x2.0(φ45-52)x3 M64x2.0(φ37-44)x3 55 120 806 856 45 1078 - -
450 800 1000 510 130 250 32 119 450 42 M56x2.0(φ32-38)x9 M64x2.0(φ37-44)x3 105 190 990 1016 52 1420 1300 2635
