YZR Series Wound-Rotor Three-Phase Induction Motor for Crane and Metallurgical Applications

Duty S3 40% 6 Starts/Hour Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Frame	Syn Speed r/min	Rated Power kW	Rated Current A	Rated Rotor Current A	Tmax/Tn	No-load Current A	Speed r/min	Eff %	Power Factor cosφ	Rotor Voltage	Moment of inertia kg·m²	Weight kg
112M	1000	1.5	4.6	12.5	2.3	3.37	866	62.9	0.79	100	0.03	73.5
132M1	1000	2.2	6.1	12.6	2.9	4.04	908	73	0.76	132	0.06	96.5
132M2	1000	3.7	9.2	14.5	2.5	5.58	908	77	0.8	185	0.07	107.5
160M1	1000	5.5	15	25.7	2.6	7.95	930	75.7	0.74	138	0.12	153.5
160M2	1000	7.5	18	26.5	2.8	11.2	940	79.4	0.8	185	0.15	159.5
160L	1000	11	24.9	27.6	2.5	13	945	82	0.82	250	0.2	174
180L	1000	15	33.8	46.5	3.2	18.8	962	83	0.81	218	0.39	230
200L	1000	22	49.5	69.9	2.88	26.6	964	86	0.803	200	0.67	390
225M	1000	30	62	74.4	3.1	29.9	962	88.3	0.83	250	0.84	398
250M1	1000	37	70.5	91.5	3.1	26.5	960	89.2	0.9	250	1.52	512
250M2	1000	45	84.5	95	3.1	28.2	965	90.6	0.89	290	1.78	559
280S	1000	55	101.5	119.8	3	34	969	89	0.9	280	2.35	746.5
280M	1000	75	138	122.6	3.1	50	969	91	0.906	370	2.86	840
160L	750	7.5	19.1	23	2.7	12.7	705	83	0.73	205	0.2	172
180L	750	11	27	44	2.7	14.8	700	81	0.77	172	0.38	230
200L	750	15	33.5	53.5	2.9	17.7	712	85	0.79	178	0.67	317
225M	750	22	46.9	59.1	2.9	24.2	715	87.4	0.82	232	0.84	390
250M1	750	30	63.4	68.8	2.8	31.4	720	87	0.8	272	1.52	515
250M2	750	37	78	70	2.8	36.9	720	85	0.8	335	1.78	563
280S	750	45	93.5	94	3.1	48.5	723	89	0.81	305	2.35	745
280M	750	55	110.5	92.5	2.8	52.3	725	89.5	0.84	360	2.86	847.5
315S	750	75	134	159	2.9	62	727	89.5	0.87	302	7.22	1050
315M	750	90	172	160.9	3.1	57.7	720	90.2	0.88	372	8.68	1170
280S	600	37	84.8	153.2	2.8	44.2	572	87	0.76	150	2.35	766
280M	600	45	103.8	165	3.2	63.6	560	85.6	0.78	172	2.86	840
315S	600	55	118.3	138.7	3.1	62.5	580	89.3	0.79	242	7.22	1026
315M	600	75	160	149.3	3.1	85.3	579	89.7	0.79	325	8.68	1156
355M	600	90	180	166.6	3.1	83	589	92.1	0.825	330	14.32	1520
355L1	600	110	217	172	2.9	90	582	92.2	0.84	388	17.08	1764
355L2	600	132	262	167.5	3.3	126	588	92.4	0.815	475	19.18	1810
400L1	600	160	339	250	3	182	588	91	0.79	395	20.81	2400
400L2	600	200	423	258	2.85	213	589	92	0.77	460	24.52	2950

Duty S3 40% 6 Starts/Hour Specification of YZR Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Duty S3 15%_25%_60%_100% Specification of YZR Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Duty S3 15%_25%_60%_100% Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Frame	Syn Speed r/min	Eff %	Power Factor cosφ	Rotor Voltage V	Moment of inertia kg·m²	Weight kg	15% Rated Power KW	15% Rated Current A	15% Rated Rotor Current A	15% Speed r/min	25% Rated Power kW	25% Rated Current A	25% Rated Rotor Current A	25% Speed r/min	60% Rated Power kW	60% Rated Current A	60% Rated Rotor Current A	60% Speed r/min	100% Rated Power kW	100% Rated Current A	100% Rated Rotor Current A	100% Speed r/min
112M	1000	62.9	0.79	100	0.03	73.5	2.2	6.6	18.4	725	1.8	5.3	13.4	815	1.1	3.8	7.3	912	0.8	3.5	5.16	940
132M1	1000	73	0.76	132	0.06	96.5	3	8	16.1	855	2.5	6.5	12.9	892	1.8	5.4	9	924	1.5	5	7.3	940
132M2	1000	77	0.8	185	0.07	107.5	5	12.3	18.2	875	4	9.7	14.2	900	3	7.9	10.2	937	2.5	7.2	8.4	950
160M1	1000	75.7	0.74	138	0.12	153.5	7.5	18.5	35.4	910	6.3	16.4	29.4	921	5	14	22.9	935	4	12.5	18.2	944
160M2	1000	79.4	0.8	185	0.15	159.5	11	24.6	39.6	908	8.5	19.6	29.8	930	6.3	16	21.7	949	5.5	15	18.8	956
160L	1000	82	0.82	250	0.2	174	15	34.7	39	920	13	28.6	31.6	942	9	21	22.3	952	7.5	18.8	18.5	970
180L	1000	83	0.81	218	0.39	230	20	42.6	58.7	946	17	36.7	49.8	955	13	29.7	37.3	968	11	25.5	31.4	975
200L	1000	86	0.803	200	0.67	390	33	62	68	942	26	56.1	82.4	956	19	44.5	60.5	969	17	40.5	52.6	973
225M	1000	88.3	0.83	250	0.84	398	40	80	101	947	34	70	85	957	26	55	64.5	968	22	50	54.2	975
250M1	1000	89.2	0.9	250	1.52	512	50	99	123	950	42	80	103	960	32	61	79	970	28	55	69	975
250M2	1000	90.6	0.89	290	1.78	559	63	121	134	947	52	97	110	958	39	73	83	969	33	64	71	974
280S	1000	89	0.9	280	2.35	746.5	75	144	169.5	960	63	118	142	966	48	88	107.1	972	40	76	88.9	976
280M	1000	91	0.906	370	2.86	840	100	185	166	960	85	157	140	966	63	118	104	975	50	96.3	82	980
160L	750	83	0.73	205	0.2	172	11	27.5	35.3	676	9	22.4	28.1	694	6	16.4	18.2	717	5	14	15	724
180L	750	81	0.77	172	0.38	230	15	34	56	690	13	29.1	47.8	700	9	21.9	32.1	720	7.5	19.6	26.6	726
200L	750	85	0.79	178	0.67	317	22	48	81	690	18.5	40	67.2	701	13	30	46.1	718	11	27	38.7	723
225M	750	87.4	0.82	232	0.84	390	33	70	92	696	26	55	71.2	708	18.5	41	49.5	721	17	38	45	723
250M1	750	87	0.8	272	1.52	515	42	75	97.5	710	35	64	80	715	26	52	59.1	725	22	46	49.7	729
250M2	750	85	0.8	335	1.78	563	52	103	98	706	42	86	79	716	32	68	60	725	27	60	51	729
280S	750	89	0.81	305	2.35	745	60	120	126	713	51	106	108	718	38	82	80	728	34	75	70.5	729
280M	750	89.5	0.84	360	2.86	847.5	75	150	132	715	63	126	110	722	48	103	82.8	730	40	93	68.7	732
315S	750	89.5	0.87	302	7.22	1050	100	172	213	719	85	148	180	724	63	116	132	731	55	104	115	734
315M	750	90.2	0.88	372	8.68	1170	125	250	232	717	100	190	183.5	715	75	140	136	725	63	124	113.8	728
280S	600	87	0.76	150	2.35	766	55	112	235.2	564	42	92	177.1	571	32	77	133.4	578	27	69	111.8	582
280M	600	85.6	0.78	172	2.86	840	63	146	241	548	55	127	207	556	37	90	136	569	33	89.6	118	587
315S	600	89.3	0.79	242	7.22	1026	75	154	194	574	63	132.5	161.9	580	48	106.6	122	585	40	95.2	101	588
315M	600	89.7	0.79	325	8.68	1156	100	210	203	570	85	179	171	576	63	140	124.8	584	50	125	98.5	587
355M	600	92.1	0.825	330	14.32	1520	132	266	252	576	110	218	207	581	75	154	140	588	63	136	117	589
355L1	600	92.2	0.84	388	17.08	1764	160	314	261	571	132	257	213	578	90	181	143	585	75	157	119	588
355L2	600	92.4	0.815	475	19.18	1810	185	353	241	585	150	293	194	588	110	226	141.8	591	90	191	115.6	592
400L1	600	91	0.79	395	20.81	2400	236	472	370	582	190	390	300	585	135	300	210	590	110	263	174	592
400L2	600	92	0.77	460	24.52	2950	270	540	340	582	240	490	308	586	177	372	224	591	145	332	183	592

Duty S2 Specification of YZR Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Duty S2 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Frame	Syn Speed r/min	Eff %	Power Factor cosφ	Rotor Voltage V	Moment of inertia kg·m2	Weight kg	30Minutes Rated Power KW	30Minutes Rated Current A	30Minutes Rated Rotor Current A	30Minutes Speed r/min	60 Minutes Rated Power KW	60Minutes Rated Current A	60Minutes Rated Rotor Current A	60Minutes Speed r/min
112M	1000	62.9	0.79	100	0.03	73.5	1.8	5.3	13.4	815	1.5	4.63	12.5	866
132M1	1000	73	0.76	132	0.06	96.5	2.5	6.5	12.9	892	2.2	6.05	12.6	908
132M2	1000	77	0.8	185	0.07	107.5	4	9.7	14.2	900	3.7	9.2	14.5	908
160M1	1000	75.7	0.74	138	0.12	153.5	6.3	16.4	29.4	921	5.5	15	25.7	930
160M2	1000	79.4	0.8	185	0.15	159.5	8.5	19.6	29.8	930	7.5	18	26.5	940
160L	1000	82	0.82	250	0.2	174	13	28.6	31.6	942	11	24.5	27.6	957
180L	1000	83	0.81	218	0.39	230	17	36.7	49.8	955	15	33.8	46.5	962
200L	1000	86	0.803	200	0.67	390	26	56.1	82.4	956	22	49.1	69.9	964
225M	1000	88.3	0.83	250	0.84	398	34	70	85	957	30	62	74.4	962
250M1	1000	89.2	0.9	250	1.52	512	42	80	103	960	37	70.5	91.5	965
250M2	1000	90.6	0.89	290	1.78	559	52	97	110	958	45	84.5	95	965
280S	1000	89	0.9	280	2.35	746.5	63	118	142	966	55	101.5	129.8	969
280M	1000	91	0.906	370	2.86	840	85	157	140	966	75	139	124	970
160L	750	83	0.73	205	0.2	172	9	22.4	28.1	694	7.5	19.1	23	705
180L	750	81	0.77	172	0.38	230	13	29.1	47.8	700	11	27	44	700
200L	750	85	0.79	178	0.67	317	18.5	40	67.2	701	15	33.5	53.5	712
225M	750	87.4	0.82	232	0.84	390	26	55	71.2	708	22	46.9	59.1	715
250M1	750	87	0.8	272	1.52	515	35	64	80	715	30	63.4	67.7	720
250M2	750	85	0.8	335	1.78	563	42	86	79	716	37	78	70	720
280S	750	89	0.81	305	2.35	745	52	108	106	712	45	93.5	94	723
280M	750	89.5	0.84	360	2.86	847.5	63	126	110	722	55	110.5	92.5	725
315S	750	89.5	0.87	302	7.22	1050	85	148	180	724	75	134	159	727
315M	750	90.2	0.88	372	8.68	1170	100	190	183	715	90	172	160.9	720
280S	600	87	0.76	150	2.35	766	42	92	177.1	571	37	84.8	153.2	560
280M	600	85.6	0.78	172	2.86	840	55	127	207	556	45	103.8	165	560
315S	600	89.3	0.79	242	7.22	1026	63	132	161.9	580	55	118.3	138.7	580
315M	600	89.7	0.79	325	8.68	1156	85	179	171	576	75	160	149.3	579
355M	600	92.1	0.825	330	14.32	1520	110	218	207	581	90	180	166.6	585
355L1	600	92.2	0.84	388	17.08	1764	132	257	213	576	110	217	172	582
355L2	600	92.4	0.815	475	19.18	1810	150	275	194	588	132	262	167.5	588
400L1	600	91	0.79	395	20.81	2400	190	390	290	585	160	339	250	588
400L2	600	92	0.77	460	24.52	2950	240	490	302	585	200	427	258	588

Duty S4-S5 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Frame	Syn Speed r/min	Eff %	Power Factor cosφ	Rotor Voltage V	Moment of inertia kg·m2	Weight kg	150 Starts/Hour 25% Rated Power kw	150 Starts/Hour 25%Rated Current A	150 Starts/Hour 25% Rated Rotor Current A	150 Starts/Hour 25%Speed r/min	150 Starts/Hour 40% Rated Power kw	150 Starts/Hour 40% Rated Current A	150 Starts/Hour 40% Rated Rotor Current A	150 Starts/Hour 40% Speed r/min	150 Starts/Hour 60% Rated Power kw	150 Starts/Hour 60% Rated Current A	150 Starts/Hour 60% Rated Rotor Current A	150 Starts/Hour 60% Speed r/min	300 Starts/Hour 40% Rated Power kw	300 Starts/Hour 40% Rated Current A	300 Starts/Hour 40% Rated Rotor Current A	300 Starts/Hour 40% Speed r/min	300 Starts/Hour 60% Rated Power kw	300 Starts/Hour 60% Rated Current A	300 Starts/Hour 60% Rated Rotor Current A	300 Starts/Hour 60% Speed r/min	600 Starts/Hour 60% Rated Power kw	600 Starts/Hour 60% Rated Current A	600 Starts/Hour 60% Rated Rotor Current A	600 Starts/Hour 60% Speed r/min
112M-6	1000	62.9	0.79	100	0.03	73.5	1.6	4.75	11.3	845	1.3	4.2	8.85	890	1.0	3.75	6.57	920	1.2	4.0	8.0	900	0.9	3.7	5.87	930	0.7	3.4	4.46	946
132M1-6	1000	73	0.76	132	0.06	96.5	2.2	6	11.2	908	2	5.7	10	913	1.7	5.3	8.4	931	1.8	5.4	8.95	926	1.6	5.1	7.87	936	1.35	4.9	6.8	945
132M2-6	1000	77	0.8	185	0.07	107.5	3.7	9.7	13.1	915	3.5	9.2	11.2	925	2.8	8.5	9.65	940	3.3	9.4	11.9	925	2.8	8.5	9.65	940	2.3	6	7.5	950
160M1-6	1000	75.7	0.74	138	0.12	153.5	5.8	15.5	27.3	927	5	14.1	23.4	935	4.8	13.8	22.7	937	4.8	14.1	23.4	935	4.5	13.8	22.4	937	3.8	12.2	17.5	946
160M2-6	1000	79.4	0.8	185	0.15	159.5	7.5	18	27.6	940	7	17.1	25.6	945	6.0	15.6	21.8	954	6.0	15.6	21.8	954	5.5	14.8	19.8	959	4.0	13	14.2	970
160L-6	1000	82	0.82	250	0.2	174	11	28.3	27.8	950	10	23	25	957	8	19.5	19.8	969	8.0	19.5	19.8	969	7.5	18.7	18.5	971	5.6	16.7	14.2	978
180L-6	1000	83	0.81	218	0.39	230	15	33	43.7	960	13	29.5	37.7	965	12	28	34.6	969	12	28	34.6	969	11	26.6	31.7	972	9	23.6	22.9	978
200L-6	1000	86	0.803	200	0.67	390	21	47	55.4	965	18.5	42.5	48.5	970	17	40.5	53.8	973	17	40.5	52.5	973	15	37	40	975	11	31.5	28.5	981
225M-6	1000	88.3	0.83	250	0.84	398	28	58	70	965	25	53	62.2	969	22	50	54.5	973	22	50	54.5	973	20	46	49.4	977	15	39	36.8	982
250M1-6	1000	89.2	0.9	250	1.52	512	33	63	82.6	970	30	58	74.9	973	28	54	69.8	975	26	52	64.6	977	25	50	62.1	978	17.5	39	43.2	984
250M2-6	1000	90.6	0.89	290	1.78	559	42	78	90.5	967	37	70	79.3	971	33	63	70.5	975	31	60	66.1	976	30	58	63.9	977	24	49	50.9	981
280S-6	1000	89	0.9	280	2.35	746.5	52	95	116	970	45	83	100	974	42	80	93.6	975	40	76	89	977	37	71	82.2	978	30	64	66.5	980
280M-6	1000	91	0.906	370	2.86	840	70	130	115	972	62	114	102	975	55	90	104	975	52	98	85.5	979	47	92	77	981	37	78	61	982
160L-8	750	83	0.73	205	0.2	172	7.5	19	22.8	712	7	18.1	21.2	716	5.8	16.4	17.3	724	6.0	16.7	18	722	5.5	15.5	14.9	727	3.8	13.7	11.2	732
180L-8	750	81	0.77	172	0.38	230	11	25.4	40.6	711	10	23.5	36.6	717	8	20.5	28.8	728	8.0	20.5	28.8	728	7.5	19.7	26.9	729	5.8	17.8	20.6	736
200L-8	750	85	0.79	178	0.67	317	15	34	54.1	713	13	30	46.6	718	12	28.5	43	720	12	28.2	43	720	11	27	39.1	724	8.0	23	28.1	731
225M-8	750	87.4	0.82	232	0.84	390	21	45	56.8	718	18.5	41	49.7	721	17	38	45.6	724	17	38	45.6	724	15	35.1	40	727	11	31	29.1	733
250M1-8	750	87	0.8	272	1.52	515	29	61.5	68.5	700	25	54	58.7	705	22	49	51.9	712	22	49	51.9	712	20	46	46.2	716	15	39	34.2	725
250M2-8	750	85	0.8	335	1.78	563	33	70	62.5	725	30	64	56.6	727	28	61	52.8	728	26	58	48.9	730	25	57	47	731	18.5	45	34.4	736
280S-8	750	89	0.81	305	2.35	745	42	91	85.5	719	37	83	75.6	722	33	76.2	67	726	31	74	63	728	30	72	61.5	732	24	64	49.1	733
280M-8	750	89.5	0.84	360	2.86	847.5	52	104	90.2	727	45	93	77.7	730	42	89	72.4	732	42	89	72.4	732	37	83	63.5	735	30	73	51.4	737
315S-8	750	89.5	0.87	302	7.22	1050	64	118	132.7	731	60	110.5	124.2	733	56	106	115.8	733	52	100	107	735	48	94	98.8	736	35	80	71.7	740
315M-8	750	90.2	0.88	372	8.68	1170	75	142	136	725	72	136	130.7	725	65	126	117.6	727	60	120	108	729	55	116	99	729	41	100	73.7	732
280S-10	600	87	0.76	150	2.35	766	33	78.7	141.8	578	30	74	125	579	28	71	116	580	26	68	108	582	25	66	103	583	17	56	69.8	588
280M-10	600	85.6	0.78	172	2.86	840	42	98.7	154	575	37	90	136	570	33	84	118	573	31	82	110	574	28	78.5	98	577	22	72.5	75	582
315S-10	600	89.3	0.79	242	7.22	1026	50	110	128.4	583	45	100	115.3	585	42	96	107.4	586	40	94	102.2	587	37	90	94.5	587	30	84	76.3	589
315M-10	600	89.7	0.79	325	8.68	1156	65	144	129	584	60	136	119	585	55	130	109	586	50	126	98.7	587	48	124	94.7	588	37	114	73	589
355M-10	600	92.1	0.825	330	14.32	1520	80	160.5	149.7	587	72	156	134.5	588	65	140	121	589	60	130	112	590	55	124	102.4	590	41	104	76.19	591
355L1-10	600	92.2	0.84	388	17.08	1764	100	185	159	586	90	170	142	588	80	155	126.5	589	75	150	119	590	70	145	111	591	50	120	78.4	594
355L2-10	600	92.4	0.815	475	19.18	1810	120	250	149.8	588	110	230	137.5	589	95	210	122.7	591	90	205	116.2	591	80	190	130.2	592	60	165	77.1	594
400L1-10	600	91	0.79	395	20.81	2400	145	314	223	588	132	290	199	589	120	278	180	590	110	260	168	591	96	247	148	592	75	220	114	594
400L2-10	600	92	0.77	460	24.52	2950	185	396	238	590	165	365	262	589	150	342	195	592	140	324	180	592	120	298	155	592	95	265	122	594

IM1001_IM1002_IM1003 Mounting of YZR Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

IM1001_IM1002_IM1003 Mounting of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Frame	H	A	B	C	CA	K	d	ac	b	h	l	11	lc	D	D1	D2	E	E1	E2	E3	F	F1	G
112M	112	190	140	70	300	12	M10	245	250	330	235	590	670	32	-	32	80	-	80	-	10	10	27
132M	132	216	178	89	300	12	M10	285	275	360	260	645	727	38	-	38	80	-	80	-	10	10	33
160M	160	254	210	108	330	15	M12	325	320	420	290	758	868	48	-	48	110	-	110	-	14	14	43
160L	160	254	254	108	330	15	M12	325	320	420	335	800	912	48	-	48	110	-	110	-	14	14	43
180L	180	279	279	121	360	15	M12	360	360	460	380	870	980	55	M36×3	55*	110	82	110	82	14	14	20
200L	200	318	305	133	400	19	M16	405	405	510	400	975	1118	60*	M42×3	60*	140	105	140	105	16	16	21
225M	225	356	311	149	450	19	M16	430	455	545	410	1050	1190	65*	M42×3	65*	140	105	140	105	16	16	24
250M	250	406	349	168	540	24	M20	480	515	605	510	1195	1337	70*	M48×3	70*	140	105	140	105	18	18	25.4
280S	280	457	368	190	540	24	M20	535	575	665	530	1265	1438	85*	M56×4	85*	170	130	170	130	20	20	31.7
280M	280	457	419	190	540	24	M20	535	575	665	580	1315	1489	85*	M56×4	85*	170	130	170	130	20	20	32
315S	315	508	406	216	600	28	M24	620	640	750	580	1390	1562	95*	M64×4	95*	170	130	170	130	22	22	35
315M	315	508	457	216	600	28	M24	620	640	750	630	1440	1613	95*	M64×4	95*	170	130	170	130	22	22	35
355M	355	610	560	254	630	28	M24	710	740	840	730	1650	1864	110*	M80×4	110*	210	165	210	165	25	25	42
355L	355	610	630	254	630	28	M24	710	740	840	800	1720	1934	110*	M80×4	110*	210	165	210	165	25	25	42
400L	400	686	710	280	630	35	M30	840	855	950	910	1865	2120	130	M100×4	130	250	200	250	200	28	28	50

Wuxi Chaoqi Electric Motor Co.,Ltd

Low Voltage Electric Motors

YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S3 40% 6 Starts/Hour Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S3 15%_25%_60%_100% Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S2 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S4-S5 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

IM1001_IM1002_IM1003 Mounting of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Leave a Reply

Low Voltage Electric Motors

Duty S3 40% 6 Starts/Hour Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S3 15%_25%_60%_100% Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S2 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Duty S4-S5 Specification of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

IM1001_IM1002_IM1003 Mounting of YZR Series Woud-Rotor Three-Phase Induction Motor for for Crane and Metallurgical Applications

Related Products

YKS Series High Voltage Motor

YBZR Series Flameproof Wound-Rotor Three-Phase Induction Motor for Crane Applications

YSL Series (IP23) Series Three-Phase Induction Motor for Water Conservancy and Biochemitry

YZPE Series Electromagnetic Braking Variable-Frequency Adjustable-Speed Three-phase Induction Motor for Crane and Metallurgical Applications

YBZP Series Flame-proof Variable-frequency Adjustable-speed Three-phase Induction Motors for Crane Application

YZW Series - Eddy Current VFD Three-Phase Induction Motor for Tower Crane Slewing

Leave a Reply
