YSL Series (IP23) Three-Phase Induction Motor for Water Conservancy and Biochemistry

Spefication of YSL Series (IP23) Three-Phase Induction Motor for Water Conservancy and Biochemitry

Motor model	Rated power KW	Stator current A	Rated speed r/min	Efficiency %	Power factor cosφ	Maximum torque /Rated torque	Starting torque /Rated torque	Starting current /Rated current	Noise dBA	Moment of inertia kg.m²
4502-4	225	408	1482	93	0.9	2	1.3	6.5	106	7.6
4503-4	260	472	1483	93	0.9	2	1.3	6.5	106	8.6
4504-4	300	536	1482	93.5	0.91	2	1.3	6.5	106	10
4501-6	130	243	984	91.5	0.89	1.8	1.1	6	100	7.6
4502-6	155	289	985	91.5	0.89	1.8	1.1	6	100	8.7
4503-6	185	343	985	92	0.89	1.8	1.1	6	100	10.1
4504-6	215	399	984	92	0.89	1.8	1.1	6	100	11.7
5001-6	240	438	985	92.5	0.9	1.8	1.2	6	103	16.8
5002-6	280	508	986	93	0.9	1.8	1.2	6	103	19.1
5002-6A	320	578	985	93.5	0.9	1.8	1.2	6	103	21.4
4501-8	95	187	737	91	0.85	1.6	0.9	5.5	93	8.5
4502-8	110	216	738	91	0.85	1.6	0.9	5.5	93	9.6
4503-8	130	253	737	92	0.85	1.6	0.9	5.5	97	10.6
4504-8	155	301	738	92	0.85	1.6	0.9	5.5	97	12.3
4505-8	180	350	737	92	0.85	1.6	0.9	5.5	97	14.4
4505-8B	185	359	738	92	0.85	1.6	0.9	5.5	97	14.4
5001-8	180	350	738	92	0.85	1.8	1.2	5.5	97	16.5
5002-8	210	403	737	92	0.86	1.8	1.2	5.5	97	19.5
5003-8	245	468	736	92.5	0.86	1.8	1.2	5.5	99	22.5
5003-8A	260	494	737	93	0.86	1.8	1.3	5.5	99	23.7
5003-8B	280	532	737	93	0.86	1.8	1.3	5.5	99	25
5003-8C	320	608	738	93	0.86	1.8	1.3	5.5	99	27.4
4501-10	80	164	586	90.5	0.82	1.6	1.2	5.5	93	9.3
4502-10	95	195	587	90.5	0.82	1.6	1.2	5.5	93	10.3
4503-10	115	234	587	91	0.82	1.6	1.2	5.5	97	12.4
4504-10	130	265	587	91	0.82	1.6	1.2	5.5	97	14.1
5001-10	155	298	585	92	0.86	1.6	0.9	5	97	16.5
5002-10	180	344	585	92.5	0.86	1.6	0.9	5	97	19.3
5002-10A	210	406	588	92.5	0.85	1.8	1.1	5	97	21.5
5002-10B	240	464	587	92.5	0.85	1.8	1.1	5	99	24.2

MB3 Mounting Size of YSL Series (IP23) Three-Phase Induction Motor for Water Conservancy and Biochemitry

Frame	D	E	F	G	M	N	P	n	S	T	H	H1	H2	L
4502-4	85	170	24	78	875	825	950	8	24	6	10	30	590	1430
4503-4	85	170	24	78	875	825	950	8	24	6	10	30	590	1430
4504-4	85	170	24	78	875	825	950	8	24	6	10	30	590	1430
4501-6	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4501-8	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4501-10	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4502-6	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4502-8	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4502-10	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4503-6	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4503-8	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4503-10	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4504-6	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4504-8	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4504-10	90	170	24	83	875	825	950	8	24	6	10	30	590	1430
4505-8	100	170	28	92	875	825	950	8	24	6	10	30	590	1430
4505-8B	100	170	28	92	875	825	950	8	24	6	10	30	590	1430
5001-6	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5001-8	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5002-8	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5002-10	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5002-6	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5003-8	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5003-10	100	210	28	92	975	925	1060	8	24	6	10	30	690	1500
5002-6A	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
5003-8A	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
5003-10A	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
5003-8B	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
5003-10B	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
5003-8C	110	210	32	101	975	925	1060	8	24	6	10	30	690	1600
