| 参数 | 值 |
|---|---|
| 额定功率 | 600kW |
| 额定电压 | 600V |
| 额定电流 | 728A |
| 额定频率 | 51Hz |
| 额定转速 | 505r/min |
| 额定转矩 | 11346N.m |
| 最大转矩 | 17019N.m |
| 额定效率 | 95.3% |
| 额定功率因数 | 0.832 |
| 级数 | 12 |
| 工作制 | S1 |
| 绝缘等级 | 200 |
| 主机防护等级 | IP44 |
| 接线盒防护等级 | IP55 |
| 冷却方式 | CO6(强迫通风Forced ventilation |
| 风机电机 | 3KW 380V 50Hz ExdIIBT4 |
| 防爆等级 | 满足二类二区防爆Meet the requirements of the two zone explosion protection |
YJC Series - Three-Phase Induction Direct Drive Motor for Oil Rig Mud Pumps
