YZ Series Three-Phase Induction Motor for Crane and Metallurgical Applications

Duty S3 40% 6 Starts/Hour Spefication of YZ Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Frame	Syn Speed /min	Rated Power (KW)	Rated Current (A)	Rated Speed (r/min)	Tmax/Tn	Ts/Tn	Ist/In	Eff%	Power Factor cosφ	Moment of inertia kg·m 2	Weight (kg)
YZ112M	1000	1.5	4.25	920	2.7	2.44	4.47	69.5	0.765	0.02	58
YZ132M1	1000	2.2	5.9	935	2.9	3.1	5.16	74	0.745	0.053	80
YZ132M2	1000	3.7	8.8	912	2.8	3	5.54	79	0.79	0.058	91.5
YZ160M1	1000	5.5	12.5	933	2.7	2.5	4.9	80.6	0.83	0.105	118.5
YZ160M2	1000	7.5	15.9	948	2.9	2.4	5.52	83	0.84	0.133	131.5
YZ160L	1000	11	24.6	953	2.9	2.7	6.17	84	0.85	0.178	152
YZ160L	750	7.5	18	705	2.7	2.5	5.1	82	0.74	0.178	152
YZ180L	750	11	25.8	694	2.5	2.6	4.9	80.9	0.811	0.33	205
YZ200L	750	15	33.1	710	2.8	2.7	6.1	85	0.8	0.58	276
YZ225M	750	22	45.8	712	2.9	2.9	6.2	84	0.83	0.75	347
YZ250M1	750	30	63.3	694	2.54	2.7	5.47	85	0.84	1.33	462

Duty S3 Non-40% 6 Starts/Hour Spefication of YZ Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Frame	Syn Speed (r/min)	15% Rated Power (KW)	15% Rated Current (A)	15% Rated Speed (r/min)	25% Rated Power (KW)	25% Rated Current (A)	25% Rated Speed (r/min)	60% Rated Power (KW)	60% Rated Current (A)	60% Rated Speed (r/min)	100% Rated Power (KW)	100% Rated Current (A)	100% Rated Speed (r/min)
YZ112M	1000	2.2	6.5	810	1.8	4.9	892	1.1	2.7	946	0.8	3.5	980
YZ132M1	1000	3	7.5	804	2.5	6.5	920	1.8	5.3	950	1.5	4.9	960
YZ132M2	1000	5	11.6	890	4	9.2	915	3	7.5	940	2.8	7.2	945
YZ160M1	1000	7.5	16.8	903	6.3	14.1	922	5	11.5	940	4	10	953
YZ160M2	1000	11	25.4	926	8.5	18	943	6.3	14.2	956	5.5	13	961
YZ160L	1000	15	32	920	13	28.7	936	9	20.6	964	7.5	18.8	972
YZ160L	750	11	27.4	675	9	21.1	694	6	15.6	717	5	14.2	724
YZ180L	750	15	35.3	654	13	30	675	9	21.5	710	7.5	19.2	718
YZ200L	750	22	47.5	686	18.5	40	697	13	28.1	714	11	26	720
YZ225M	750	33	69	687	26	53.5	701	18.5	40	718	17	37.5	720
YZ250M1	750	42	89	663	35	74	681	26	56	702	22	45	717

Duty S2 Spefication of YZ Series Three-Phase Induction Motor for Lifting and Metallurgical Applications

Duty S2 Spefication of YZ Series Three-Phase Induction Motor for Crane and Metallurgical Applications

Frame	Syn Speed r/min	30 Minutes Rated Power (KW)	30 Minutes Rated Current (A)	30 Minutes Rated Speed (r/min)	60 Minutes Rated Power (KW)	60 Minutes Rated Current (A)	60 Minutes Rated Speed (r/min)	Tmax/Tn	Ts/Tn	Ist/In	Eff%	Power Factor cosφ	Moment of inertia kg·m	Weight (kg)
YZ112M	1000	1.8	4.9	892	1.5	4.25	920	2.7	2.44	4.47	69.5	0.765	0.02	58
YZ132M1	1000	2.5	6.5	920	2.2	5.9	935	2.9	3.1	5.16	74	0.745	0.053	80
YZ132M2	1000	4	9.2	915	3.7	8.8	912	2.8	3	5.54	79	0.79	0.058	91.5
YZ160M1	1000	6.3	14.1	922	5.5	12.5	933	2.7	2.5	4.9	80.6	0.83	0.105	118.5
YZ160M2	1000	8.5	18	943	7.5	15.9	948	2.9	2.4	5.52	83	0.84	0.133	131.5
YZ160L	1000	15	32	920	11	24.6	953	2.9	2.7	6.17	84	0.85	0.178	152
YZ160L	750	9	21.1	694	7.5	18	705	2.7	2.5	5.1	82	0.74	0.178	152
YZ180L	750	13	30	675	11	25.8	694	2.5	2.6	4.9	80.9	0.811	0.33	205
YZ200L	750	18.5	40	697	15	33.1	710	2.8	2.7	6.1	85	0.8	0.58	276
YZ225M	750	26	53.5	701	22	45.8	712	2.9	2.9	6.2	84	0.83	0.75	347
YZ250M1	750	35	74	681	30	63.3	694	2.54	2.7	5.47	85	0.84	1.33	462

IM1001_IM1002_IM1003 Mounting of YZ Series Three-Phase Induction Motor for Crane and Metallurgical Applications

Frame	H	A	B	C	CA	K	d	ac	b	h	l	l1	lc	D	D1	D2	E	E1	E2	E3	F	F1	G
112M	112	190	140	70	300	12	M10	245	250	330	235	590	670	32	-	32	80	-	80	-	10	10	27
132M	132	216	178	89	300	12	M10	285	275	360	260	645	727	38	-	38	80	-	80	-	10	10	33
160M	160	254	210	108	330	15	M12	325	320	420	290	758	868	48	-	48	110	-	110	-	14	14	42.5
160L	160	254	254	108	330	15	M12	325	320	420	335	800	912	48	-	48	110	-	110	-	14	14	42.5
180L	180	279	279	121	360	15	M12	360	360	460	380	870	980	55*	M36×3	55*	110	82	110	82	14	14	19.9
200L	200	318	305	133	400	19	M16	405	405	510	400	975	1118	60*	M42×3	60*	140	105	140	105	16	16	21.4
225M	225	356	311	149	450	19	M16	430	455	545	410	1050	1190	65*	M42×3	65*	140	105	140	105	16	16	23.9
250M	250	406	349	168	540	24	M20	480	515	605	510	1195	1337	70*	M48×3	70*	140	105	140	105	18	18	25.4
280S	280	457	368	190	540	24	M20	535	575	665	530	1265	1438	85*	M56×4	85*	170	130	170	130	20	20	31.7
280M	280	457	419	190	540	24	M20	535	575	665	580	1315	1489	85*	M56×4	85*	170	130	170	130	20	20	31.7）
315S	315	508	406	216	600	28	M24	620	640	750	580	1390	1562	95*	M64×4	95*	170	130	170	130	22	22	35.2
315M	315	508	457	216	600	28	M24	620	640	750	630	1440	1613	95*	M64×4	95*	170	130	170	130	22	22	35.2
355M	355	610	560	254	630	28	M24	710	740	840	730	1650	1864	110*	M80×4	110*	210	165	210	165	25	25	41.9
355L	355	610	630	254	630	28	M24	710	740	840	800	1720	1934	110*	M80×4	110*	210	165	210	165	25	25	41.9
400L	400	686	710	280	630	35	M30	840	855	950	910	1865	2120	130	M100×4	130*	250	200	250	200	28	28	50
